Indoor Camera
Know what’s going on inside your home from wherever you are with an Indoor Camera that pairs with your HTC Security System.
Cameras have HD 1080p video with infrared night vision to secure your home inside and out.
Receive notifications on your mobile device when camera records.
Installation
IMPORTANT: Your system must be active and you must have an existing Alarm.com account to proceed with the camera installation steps.
1. Visit Alarm.com and login with your username and password.
2. Now visit Alarm.com/addcamera.
3. On this screen, you will choose your appropriate camera by model number. (We have included the model numbers below to hep you identify your camera and choose the correct installation tutorial)
4. Follow the step-by-step installation tutorial for your camera to complete the setup.
Specifications
| Maximum resolution | 1920×1080 |
| Recording compression | H.264, MPEG-4 |
| Image sensor | 1/2.9″ CMOS, 2.12 MP, 1920×1080 |
| Lens | 2.8 mm, F1.85 |
| Angle of view | 113° |
| Low-light sensitivity | 0 lux with IR |
| IR range | Up to 5 meters (~15 feet) |
| Image adjustments | Flip, brightness, contrast, saturation, sharpness, exposure |
| Video motion detection | 3 windows, adjustable sensitivity and threshold |
| Wireless connectivity | 802.11 b/g/n/ac, 2.4 & 5 GHz |
| Ethernet connection | 10/100Mbps RJ-45 |
| Simultaneous viewers | 10 |
| Operating temperature | 0°C – 40°C (32°F – 104°F) |
| Operating humidity | 20%-100% (non-condensing) RH |
| Max power consumption | 12 V DC, 5 W |
| Dimensions (WxH) | 2.75” x 2.06” x 3.67” |
| Two-way audio compatibility | Hardware Version 0101 and Firmware Version IP8168-ALAM-0100b9 + |
Price: $149
Cameras have HD 1080p video with infrared night vision to secure your home inside and out. Receive notifications on your mobile device when camera records.
Click to download installation instructions and information on other home automation security equipment.
